Overview
A pneumatic forklift tire built on a standard E-4 tube-and-flap assembly for everyday material-handling duty. Its rim guard protects the wheel from cuts and scuffs, and the traction tread keeps footing sure on shop and yard surfaces.
Size Specifications
| Item Number | Tire Size | Ply | O.D. | Section Width | Tread Width | Tread Depth | PSI | Load Limit 10mph |
|---|---|---|---|---|---|---|---|---|
| 05008-FL-STD | 500-8 | 8 | 18.3 | 5.5 | 4.4 | 17/32 | 115 | 1830 |
| 065010-FL-STD | 650-10 | 10 | 22.9 | 7.1 | 6.3 | 19/32 | 115 | 4225 |
| 070012-FL-STD | 700-12 | 14 | 26.9 | 8.1 | 6.8 | 19/32 | 145 | 6535 |
| 070015-FL-STD | 700-15 | 14 | 28.8 | 7.6 | 7 | 24/32 | 145 | 7495 |
| 028915-FL-STD | 815-15 | 14 | 27.9 | 9.3 | 8.3 | 24/32 | 140 | 7530 |
| 082515-FL-STD | 825-15 | 16 | 33.4 | 9.1 | 7.7 | 24/32 | 135 | 8390 |
| 025015-FL-STD | 250-15 | 18 | 28.9 | 9.4 | 8.6 | 24/32 | 150 | 10100 |
